Autonics BJ10M-TDT-C Photoelectric Sensor
The Autonics BJ10M-TDT-C Photoelectric Sensor offers Through-beam type sensing type, 10m, Red LED(660nm), NPN open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BJ Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BJ10M-TDT-C |
Autonics BJ10M-TDT-C Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Through-beam type |
| Sensing distance | 10m |
| Sensing target | Opaque material of min. Ø12mm |
| Response time | Max. 1ms |
| Light source | Red LED(660nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by switch) |
| Power supply | 12-24VDC |
| Current consumption | Emitter/Receiver: Max. 20mA |
| Control output | NPN open collector |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -25 to 55℃, storage: -40 to 70℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP67 |
| Connection type | Connector type(M8) |
| Material | Case: Polycarbonate+Acrylonitrile butadiene styrene, LED Cap: Polycarbonate, Sensing part: Polymethyl methacrylate,Bracket: SUS304(steel use stainless 304), Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum,Sleeve: Brass, Ni-plate |
| Accessories_Common | Fixing bracket, M3 Bolts: 4, M3 Nuts: 4, Adjuster driver |
| Weight | Approx. 45g (approx. 20g) |
The Autonics BJ10M-TDT-C Photoelectric Sensor delivers consistent detection with a 10m through-beam range, red LED source, 1ms response time, and NPN open collector output. As part of the Autonics BJ Series, this Photoelectric Sensor supports long-distance sensing needs in industrial automation environments across India.
This model is suitable for conveyors, packaging operations, automated inspection lines, and assembly processes requiring precise beam-based object detection. Its through-beam structure ensures stable performance over extended distances, while the Light ON/Dark ON switch provides configuration flexibility. The M8 connector allows quick installation and secure integration with industrial control hardware.
The Autonics BJ10M-TDT-C Photoelectric Sensor ensures dependable performance through its defined sensing distance, fast response characteristics, and reliable output structure. As a member of the Autonics BJ Series, it is well suited for demanding industrial applications requiring accurate long-range sensing. This model provides repeatable operation for users seeking reliable detection in continuous automation environments.
