Autonics ASL-L04MP0-UY I/O Terminal Block
The Autonics ASL-L04MP0-UY I/O Terminal Blocks offers 24VDC ยฑ10% voltage, Screwless terminal type, 5.0mm Terminal pitch, Blue LED indicator. Manufactured by Autonics under the Autonics I/O Terminal Blocks category, this model belongs to the Autonics ASS Series.
| Brand | Autonics |
| Product Type | I/O Terminal Blocks |
| Model Number | ASL-L04MP0-UY |
Autonics ASL-L04MP0-UY I/O Terminal Block โ Technical Specifications
| Specification | Value |
|---|---|
| Applied SSR | AQZ202D(Panasonic) |
| Rated voltage | 24VDC ยฑ10% |
| Current consumption | โค 3mA |
| Terminal type | Screwless |
| Terminal pitch | 5.0mm |
| Indicator | Blue LED |
| Applicable cable_Solid wire | ร0.6 to ร1.25mm(60โ only) |
| Applicable cable_Stranded wire | AWG22-16(0.30 to 1.25mmยฒ)(60โ only) |
| Rated load voltage & current | 60VAC~/DC @(=) 50/60Hz 2.7A |
| Insulation resistance | โฅ1,000Mโฆ (at 500VDC megger) |
| Dielectric strength_Between coil-contacts | 2,500VAC 50/60Hz for 1 minute |
| Dielectric strength_Between same contacts | 300VAC 50/60Hz for 1 minute |
| Accessories | Jumper bar: 1, Ejector: 1 |
| Protection structure | IP20(IEC standard) |
| Environment_Ambient temperature | -15 to 55โ, storage: -25 to 65โ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | Terminal block: Polyamide 66, Conducting plate: Brass, CASE&BASE: Poly phenylene sulfide |
| Weight | Approx. 118g(approx. 65g) |
Give Us a Call for Autonics Solid State Relay Terminal Blocks ASL-L04MP0-UY at the lowest pricing. In-depth Technical Analysis of ASL-L04MP0-UY feature 24VDC ยฑ10% rated voltage, ensuring stable and efficient operation. The current consumption is โค 3mA, optimizing energy efficiency. It features a Screwless type terminal with an 5.0mm terminal pitch, providing secure and reliable connections.
With โฅ1,000Mโฆ (at 500VDC megger) insulation resistance and dielectric strength of 2,500VAC 50/60Hz for 1 minute between coil-contacts and 300VAC 50/60Hz for 1 minute between the same contacts, this relay guarantees high electrical safety. It operates within an ambient temperature range of -15 to 55โ, storage: -25 to 65โ and humidity levels of 35 to 85% RH, storage: 35 to 85% RH, ensuring durability in industrial environments.
Constructed with Terminal block: Polyamide 66, Conducting plate: Brass, CASE&BASE: Poly phenylene sulfide brass terminal pins, it is designed for longevity. With an approximate weight of Approx. 118g(approx. 65g), it offers a robust yet lightweight design. Elevate Your Project with a Quote for your requirement of Solid State Relay Terminal Blocks. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
