Autonics AH63K-M5913W 5-Phase Stepper Motor Driver

Name: Autonics AH63K-M5913W
Brand: Autonics
SKU: AH63K-M5913W
Rating: 4.8 (4 reviews)

The Autonics AH63K-M5913W 5-Phase Stepper Motor Driver offers 128mmmotor length, Dual shaft type, Pentagon wire connection, 1.4A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.

Datasheet

Brand	Autonics
Product Type	5-Phase Stepper Motor Driver
Model Number	AH63K-M5913W

Autonics AH63K-M5913W 5-Phase Stepper Motor Driver – Technical Specifications

Specification	Value
Motor length	128mm
Shaft type	Dual shaft
Wire connection	Pentagon
Rated current	1.4A/Phase
Basic Step Angle [FULL/HALF]	0.72º/0.36º
Max. holding torque	63kgf.cm
Rotor Moment Of Inertia	4000g·cm²
Winding Resistance	3.92Ω
Protection structure	IP30
ElectroMagnetic brake_Rated excitation voltage	24VDC @(=)±10%(no-polarity)
ElectroMagnetic brake_Rated excitation current	0.62A
ElectroMagnetic brake_Static friction torque	40kgf.cm
ElectroMagnetic brake_Rotation part inertia moment	153×10@(^-7)kgf.cm²
ElectroMagnetic brake_B type brake	Power on: brake is released, power off: brake is operating
ElectroMagnetic brake_Operating time	Max. 60ms
ElectroMagnetic brake_Releasing time	Max. 15ms
Weight	Approx. 4.28kg(approx. 3.8kg)
