Home Autonics 5-Phase Stepper Motor Driver 5-Phase Series AH41K-G599 Autonics AH41K-G599 5-Phase Stepper Motor Driver The Autonics AH41K-G599 5-Phase Stepper Motor Driver offers 98mm motor length, Single shaft type, Pentagon wire connection, 2.8A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.
Brand Autonics Product Type 5-Phase Stepper Motor Driver Model Number AH41K-G599
Autonics AH41K-G599 5-Phase Stepper Motor Driver β Technical Specifications Specification Value Motor length 98mm Shaft type Single shaft Wire connection Pentagon Rated current 2.8A/Phase Basic Step Angle [FULL/HALF] 0.72ΒΊ/0.36ΒΊ Max. holding torque 41kgf.cm Rotor Moment Of Inertia 2700gΒ·cmΒ² Winding Resistance 0.58Ξ© Protection structure IP30 ElectroMagnetic brake_Rated excitation voltage 24VDC @(=)Β±10%(no-polarity) ElectroMagnetic brake_Rated excitation current 0.62A ElectroMagnetic brake_Static friction torque 40kgf.cm ElectroMagnetic brake_Rotation part inertia moment 153Γ10@(^-7)kgf.cmΒ² ElectroMagnetic brake_B type brake Power on: brake is released, power off: brake is operating ElectroMagnetic brake_Operating time Max. 60ms ElectroMagnetic brake_Releasing time Max. 15ms Weight Approx. 3.28kg(approx. 2.8kg)
