Home Autonics 5-Phase Stepper Motor Driver 5-Phase Series AH21K-G596W Autonics AH21K-G596W 5-Phase Stepper Motor Driver The Autonics AH21K-G596W 5-Phase Stepper Motor Driver offers 68mm motor length, Dual shaft type, Pentagon wire connection, 2.8A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.
Brand Autonics Product Type 5-Phase Stepper Motor Driver Model Number AH21K-G596W
Autonics AH21K-G596W 5-Phase Stepper Motor Driver β Technical Specifications Specification Value Motor length 68mm Shaft type Dual shaft Wire connection Pentagon Rated current 2.8A/Phase Basic Step Angle [FULL/HALF] 0.72ΒΊ/0.36ΒΊ Max. holding torque 21kgf.cm Rotor Moment Of Inertia 1400gΒ·cmΒ² Winding Resistance 0.4Ξ© Protection structure IP30 ElectroMagnetic brake_Rated excitation voltage 24VDC @(=)Β±10%(no-polarity) ElectroMagnetic brake_Rated excitation current 0.62A ElectroMagnetic brake_Static friction torque 40kgf.cm ElectroMagnetic brake_Rotation part inertia moment 153Γ10@(^-7)kgf.cmΒ² ElectroMagnetic brake_B type brake Power on: brake is released, power off: brake is operating ElectroMagnetic brake_Operating time Max. 60ms ElectroMagnetic brake_Releasing time Max. 15ms Weight Approx. 2.18kg(approx. 1.7kg)
